Voting styles — eight ways to fill out one 5-star ballot¶

Generated from 03c_c6_b8_style-gallery.yaml — do not edit by hand. Regenerate: python STARVote_LH_tabulation_engine/tools_adam/scripts/build_yaml_pages.py.

Method: STAR (single winner) · 1 seat · Expected winner: Bianca

Scenario¶

A gallery of legal STAR ballot styles, one voter per style: traditional (choose-one), strong backup, weak backup, partisan slate, ranked-style, nuanced, "anyone but...", and a protest (least-bad) vote. Every ballot is valid — STAR scores each candidate independently 0-5, so equal scores and skipped candidates can't spoil a ballot. Note the two Equal Support ballots in the runoff: the partisan and "anyone but" voters scored both finalists the same, so they expressed no preference between them — but their scores still helped pick the finalists. Lesson: 01_STAR/01_Learn/voting_styles/README.md

Ballots¶

The ballots as marked — the filled bubble is the score given, and the score is the number in its column:

#	Allen	Bianca	Desi	Edith	Frank
1	0	5	0	0	0
2	0	5	0	0	4
3	0	5	0	0	1
4	5	5	0	0	5
5	2	5	3	1	4
6	3	4	3	1	5
7	5	5	5	5	5
8	0	0	0	0	1

The same ballots as the file records them:

Row 1 = candidate names; each later row is one voter's 0–5 scores (a N × prefix = N identical ballots).

Allen,Bianca,Chris,Desi,Edith,Frank
    0,     5,    0,   0,    0,    0   # traditional choose-one: 5 for Bianca, nothing else
    0,     5,    0,   0,    0,    4   # strong backup: Bianca 5, Frank close behind at 4
    0,     5,    0,   0,    0,    1   # weak backup: Bianca 5, Frank a reluctant 1
    5,     5,    0,   0,    0,    5   # partisan slate: 5s for my party (A, B, F), 0s for the rest
    2,     5,    0,   3,    1,    4   # ranked-style: each score used once, like a ranking
    3,     4,    0,   3,    1,    5   # nuanced: full range, equal 3s where truly equal
    5,     5,    0,   5,    5,    5   # "anyone but Chris": max support for everyone else
    0,     0,    0,   0,    0,    1   # protest / least-bad: dislikes everyone, Frank least

What the engine says¶

The count, step by step — the rounds and how the winner is reached:

--- STAR Voting Method (single winner) ---

[STAR Voting]
 Tabulating 8 ballots.
Allen,Bianca,Chris,Desi,Edith,Frank
    0,     5,    0,   0,    0,    0
    0,     5,    0,   0,    0,    4
    0,     5,    0,   0,    0,    1
    5,     5,    0,   0,    0,    5
    2,     5,    0,   3,    1,    4
    3,     4,    0,   3,    1,    5
    5,     5,    0,   5,    5,    5
    0,     0,    0,   0,    0,    1

[STAR Voting: Scoring Round]
 The two highest-scoring candidates advance to the next round.
   Bianca        -- 34 -- First place
   Frank         -- 25 -- Second place
   Allen         -- 15
   Desi          -- 11
   Edith         --  7
   Chris         --  0
 Bianca and Frank advance.

[STAR Voting: Automatic Runoff Round]
 The candidate preferred in the most head-to-head matchups wins.
   Bianca        -- 4 -- First place
   Frank         -- 2
   Equal Support -- 2
 Bianca wins.
   Runoff math:
     8  ballots cast
   − 2  Equal Support (no preference between the two finalists)
     ─
     6  voters with a preference  (majority = 4)
           Bianca 4 (67%)  ·  Frank 2 (33%)

[STAR Voting: Winner — STAR Voting Method (single winner)]
 Bianca

Full audit — preference matrix, Condorcet, and score distribution¶

--- Runoff (Preference) Matrix ---
Head-to-head / pairwise comparison
Legend: For - Equal Support - Against
        * indicates Top 2 Finalist
               |    Allen   | * Bianca  |   Chris   |    Desi   |   Edith   | * Frank   |
-----------------------------------------------------------------------------------------
       Allen > |    ---     |0 - 3 - 5  |4 - 4 - 0  |1 - 6 - 1  |3 - 5 - 0  |0 - 3 - 5  |
    * Bianca > | 5 - 3 - 0  |   ---     |7 - 1 - 0  |6 - 2 - 0  |6 - 2 - 0  |4 - 2 - 2  |
       Chris > | 0 - 4 - 4  |0 - 1 - 7  |   ---     |0 - 5 - 3  |0 - 5 - 3  |0 - 1 - 7  |
        Desi > | 1 - 6 - 1  |0 - 2 - 6  |3 - 5 - 0  |   ---     |2 - 6 - 0  |0 - 2 - 6  |
       Edith > | 0 - 5 - 3  |0 - 2 - 6  |3 - 5 - 0  |0 - 6 - 2  |   ---     |0 - 2 - 6  |
     * Frank > | 5 - 3 - 0  |2 - 2 - 4  |7 - 1 - 0  |6 - 2 - 0  |6 - 2 - 0  |   ---     |

[Condorcet Winner]
  Condorcet Winner: Bianca — matches the STAR winner

[Condorcet Loser]
  Condorcet Loser: Chris — loses every head-to-head matchup

[Score Distribution] (how many ballots gave each star rating)
                Score
Candidate  5  4  3  2  1  0  | Total   Avg
Allen      2  0  1  1  0  4  |    15   1.9
Bianca     6  1  0  0  0  1  |    34   4.3
Chris      0  0  0  0  0  8  |     0   0.0
Desi       1  0  2  0  0  5  |    11   1.4
Edith      1  0  0  0  2  5  |     7   0.9
Frank      3  2  0  0  2  1  |    25   3.1

Everything in one file: the _tabulated mirror (regenerated on every run; every analysis forced on).

Run it yourself:

python STARVote_LH_tabulation_engine/starvote_larry_hastings.py 01_STAR/02_Examples/cases/03c_c6_b8_style-gallery.yaml
